Dimensions: 90 x 25.4 x 12 mm ( 3.54 x 1 x 0.47 Inch(es)).
2000-8000 MHz Dual Directional Coupler – 10 dB – 30 W
CD-2-2000-8000-10-10-30-SF-SF-SF
Part number: 800027This 10 dB low loss high power directional coupler covers the range 2000-8000 MHz and provides a great directivity > 15 dB. With only 1 dB of insertion loss, this product offers a good VSWR < 1.4:1 and can handle up to 30 W.
Stock: 1
Additional Information
| Fmin (MHz) | 2000 |
|---|---|
| Fmax (MHz) | 8000 |
| Coupling (dB) | 10 |
| Coupling value tolerance (dB) | 1 |
| Directivity (dB) | 15 |
| Insertion Losses (dB) | 1 |
| VSWR (Main line) | 1.5:1 |
| VSWR (Coupling Line) | 1.4:1 |
| Power Handling (W) | 30 |
| Connectors (Main Line) | SMA |
| Connectors (Coupling Line) | SMA |
| Weight (g) | 100 |
| ROHS | ROHS compliant against RoHS 10 substances (2015/863/EU) |
| Warranty | 3 years |
Product Description
This Stripline Coupler 800027 allows you to sample 10 dB of any of your signals ranging 2000 to 8000 MHz and with a continuous power < 30 W CW. Thanks to its low insertion losses < 1 dB (excluding coupling losses) and VSWR ( < 1.5:1 on main line and 1.4:1 on the coupled line), this product does not disrupt the signal you want to sample. Furthermore it provides a good directivity > 15 dB which is related to the isolation between input port and coupling port.
Because it is made on-site, DETI can ensure a quality manufacturing, therefore offering a 3 year warranty.
Please feel free to ask if you need any customisation or answers to your questions about this product.
